Brake Disc BG3530C Delphi
Product number: 1286508
Manufacturer number: BG3530C
EAN: 5012759533567
£ 66.06
Incl. VAT
In stock
Delivery 09-11-2026
Free Shipping
Secure payment
-
Free 30 days exchanges
-
Any part, any car
-
Shipment within 3 days
-
Expert support
Customer service: +31 85 070 52 25
Ask your question at our product specialists.
Questions and answers.
Fit guarantee, show parts suitable for your vehicle.
or .
-
Specifications
Outer diameter [mm] 294 Fitting Position Rear Axle Brake Disc Type Vented Surface Anticorrosion coating Coated Number of Holes 5 Brake pads Exclusive Centering Diameter [mm] 75 Inspection Tag R90 Homologated Warranty 2 years Height [mm] 59,5 Brake disc thickness (mm) 19 Minimum thickness (mm) 17,4 Wheel bolt pitch [mm] 110 Similar products of other manufacturers
Manufacturer Manufacturer number Price 7 SEVEN PARTS SV03D0215 A.B.S. 17024 A.Z. Meisterteile AZMT-44-024-1041 ABTEX BD870V AIC 51299 AISIN W6R1519S ALLIED NIPPON AND6105 AP XENERGY X602050 ASHIKA 61-00-0109C BELACO BDS1216 BLUE PRINT ADB114336 BORG & BECK BBD4184 BOSCH 0 986 478 570 BREMBO 09.7702.1X BREMBO 09.7702.11 BREMBO 09.7702.75 BREMSI CD7073V BSG BSG 15-210-026 CHAMPION 562094CH CIFAM 800-704C COMLINE ADC1723V DACO 601506 DAVID VASCO T4069 DELPHI BG3530C (this product) DENCKERMANN B130315 DON PCD18042 Dr!ve+ DBD0782C Dr!ve+ DP1010.11.0782 EUROBRAKE 5815311541 EUROBRAKE 5815201541 FAI AutoParts FPBD1467 FAI AutoParts BD566 FEBI BILSTEIN 17925 FERODO DDF1073 FERODO DDF1073C FREMAX BD-5563 FREY 845206401 FTE 9072536 GH GH-421587 GIRLING 6040692 HART 241 133 HART 224 393 HELLA 8DD 355 127-401 HELLA 8DD 355 106-571 JAPANPARTS DP-0109C JAPKO 610109C JPN 40H9065-JPN JURATEK BMW115 JURID 562094JC KAMOKA 103422 KAVO PARTS BR-10507-C KEY PARTS KBD4184 LYNXauto BN-1301 MAGNETI MARELLI 360406016802 MAGNETI MARELLI 361302040286 MAGNETI MARELLI 360406016801 MAGNETI MARELLI 360406016805 MASTER-SPORT 24011901081SE-SET-MS Manufacturer Manufacturer number Price MASTER-SPORT 24011901081-PCS-MS MASTER-SPORT 24011901081PR-PCS-MS MASTER-SPORT 24011901081PR-PCS-MSP MASTER-SPORT 24011901081SE-SET-MSP MASTER-SPORT 24011901081PR-SET-MSP MASTER-SPORT 24011901081-SET-MSP MASTER-SPORT 24011901081-PCS-MSP MASTER-SPORT 24011901081PR-SET-MS MASTER-SPORT 24011901081-SET-MS MATRIX PRO MX01423214 MAXGEAR 19-1018 MAXGEAR 19-1018MAX MAXGEAR 19-1018SPORT MAXTECH 873037 METELLI 23-0704C METZGER 6110182 MEYLE 315 523 0059 MEYLE 315 523 0059/PD MINTEX MDC1384C MINTEX MDC1384CMX MOTAQUIP LVBE272 MTR 12108582 NK 311541 NK 201541 OPEN PARTS BDR1758.20 OPTIMAL BS-6080C Omnicraft 2143280 PAGID 50449NC ProfiPower 3B2036 QUARO QD8121HC QUARO QD8121 QUINTON HAZELL BDC5147 RAICAM RD00066 RAP BRAKES R-D0640 RIDEX 82B0033 RIDEX 82B0033P ROTINGER RT 2791-GL T6 ROTINGER RT 2791-GL T5 ROTINGER RT 2791 ROTINGER RT 2791-GL T9 ROTINGER RT 2791-GL T3 ROTINGER RT 2791-GL SKF VKBD 90447 V2 STARK SKBM-2032 STELLOX 6020-1541V-SX STELLOX 6020-1541VK-SX SWAG 20 91 7925 TEXTAR 92097303 TEXTAR 92097300 TOMEX Brakes TX 72-90 TRISCAN 8120 11138C TRUSTING DF552 TRW DF4069 VAICO V20-80044 VALEO 186861 ZentParts Z06529 goCORE GCH20037 -
Applicability
BMW 3 3 (E46) | 12.1997-05.2005 318 i - 1995ccm, 136pk, 100kw - N42 B20 A 3 (E46) | 12.1997-05.2005 318 i - 1995ccm, 143pk, 105kw - N42 B20 A, N46 B20 A, N46 B20 C 3 (E46) | 12.1997-05.2005 320 d - 1995ccm, 150pk, 110kw - M47 D20 (204D4) 3 (E46) | 12.1997-05.2005 320 i - 1990ccm, 150pk, 110kw - K12B, 18 K4F, M16A, AHU, X 16 SZR, ALE, AEX, AEE, APQ, P8A (XUD11ATE), PHZ (XUD11ATE), PJZ (XUD11AT 3 (E46) | 12.1997-05.2005 320 i - 2171ccm, 163pk, 120kw - M54 B22 (226S1) 3 (E46) | 12.1997-05.2005 320 i - 2171ccm, 170pk, 125kw - M54 B22 (226S1) 3 (E46) | 12.1997-05.2005 323 i - 2494ccm, 170pk, 125kw - K12B, 18 K4F, M16A, AHU, X 16 SZR, ALE, AEX, AEE, APQ, P8A (XUD11ATE), PHZ (XUD11ATE), PJZ (XUD11AT 3 (E46) | 12.1997-05.2005 323 i - 2494ccm, 163pk, 120kw - M52 B25 (256S4) 3 (E46) | 12.1997-05.2005 325 i - 2494ccm, 192pk, 141kw - M54 B25 (256S5) 3 (E46) | 12.1997-05.2005 325 xi - 2494ccm, 192pk, 141kw - M54 B25 (256S5) 3 (E46) | 12.1997-05.2005 328 i - 2793ccm, 193pk, 142kw - S14 B23 (234EA), H, 161A (XUD7), D9B (XUD9A/U), DHY (XUD9TE/Y), KFX (TU3JP), LFZ (XU7JP), DJY (XUD9 3 Compact 3 Compact (E46) | 03.2001-02.2005 320 td - 1995ccm, 136pk, 100kw - M47 D20 (204D4) 3 Compact (E46) | 03.2001-02.2005 320 td - 1995ccm, 150pk, 110kw - M47 D20 (204D4) 3 Compact (E46) | 03.2001-02.2005 325 ti - 2494ccm, 192pk, 141kw - M54 B25 (256S5) 3 Convertible 3 Convertible (E46) | 04.2000-12.2007 318 Ci - 1995ccm, 143pk, 105kw - N42 B20 A, N46 B20 A 3 Convertible (E46) | 04.2000-12.2007 320 Cd - 1995ccm, 150pk, 110kw - M47 D20 (204D4) 3 Convertible (E46) | 04.2000-12.2007 320 Ci - 2171ccm, 163pk, 120kw - M54 B22 (226S1) 3 Convertible (E46) | 04.2000-12.2007 320 Ci - 2171ccm, 170pk, 125kw - M54 B22 (226S1) 3 Convertible (E46) | 04.2000-12.2007 323 Ci - 2494ccm, 163pk, 120kw - M52 B25 (256S4) 3 Convertible (E46) | 04.2000-12.2007 323 Ci - 2494ccm, 170pk, 125kw - M52 B25 (256S4) 3 Convertible (E46) | 04.2000-12.2007 325 Ci - 2494ccm, 192pk, 141kw - M54 B25 (256S5) 3 Coupe 3 Coupe (E46) | 12.1998-07.2006 320 Cd - 1995ccm, 150pk, 110kw - M47 D20 (204D4) 3 Coupe (E46) | 12.1998-07.2006 320 Ci - 1990ccm, 150pk, 110kw - M52 B20 (206S4) 3 Coupe (E46) | 12.1998-07.2006 325 Ci - 2494ccm, 192pk, 141kw - M54 B25 (256S5) 3 Coupe (E46) | 12.1998-07.2006 328 Ci - 2793ccm, 193pk, 142kw - M52 B28 (286S2) 3 Touring 3 Touring (E46) | 06.1999-07.2005 318 d - 1951ccm, 115pk, 85kw - M47 D20 (204D1) 3 Touring (E46) | 06.1999-07.2005 318 d - 1995ccm, 116pk, 85kw - M47 D20 (204D4) 3 Touring (E46) | 06.1999-07.2005 320 d - 1951ccm, 136pk, 100kw - M47 D20 (204D1) 3 Touring (E46) | 06.1999-07.2005 320 d - 1995ccm, 150pk, 110kw - M47 D20 (204D4) 3 Touring (E46) | 06.1999-07.2005 320 i - 1990ccm, 150pk, 110kw - M52 B20 (206S4) 3 Touring (E46) | 06.1999-07.2005 320 i - 2171ccm, 163pk, 120kw - M54 B22 (226S1) 3 Touring (E46) | 06.1999-07.2005 320 i - 2171ccm, 170pk, 125kw - M54 B22 (226S1) 3 Touring (E46) | 06.1999-07.2005 325 i - 2494ccm, 192pk, 141kw - M54 B25 (256S5) 3 Touring (E46) | 06.1999-07.2005 325 xi - 2494ccm, 192pk, 141kw - M54 B25 (256S5) 3 Touring (E46) | 06.1999-07.2005 328 i - 2793ccm, 193pk, 142kw - M52 B28 (286S2) -
Original part numbers
34216855154 BMW 34216864056 BMW 9421 685 515 BMW 3421 1165 563 BMW -
Manufacturer
Delphi has over 50 years of experience in OE supply, designing, developing and manufacturing a wide range of components for automotive manufacturers on a global basis.
Present in more than 150 countries and a global network of more than 2,750 service centers, Delphi Technologies provides aftermarket end-to-end solutions with OE specifications, from parts to advanced software solutions.
With a broad portfolio of gasoline fuel systems, diesel fuel systems, maintenance solutions, engine management and vehicle electronics, supported by OE level diagnostic and testing equipment, training and technical information, Delphi Technologies enables you to service and repair vehicles at the right time .
-
