Piston
No specifications available yet
Back to category
Piston
Product number: 1174634
Manufacturer number: 030 58 01
EAN: 4009026549490
-
Free 30 days exchanges
-
Any part, any car
-
Fast shipping: 2 days
-
Expert support
Customer service: +31 85 070 52 25
Ask your question at our product specialists.
Questions and answers.
Fit guarantee, show parts suitable for your vehicle.
or .
-
Specifications
Fitting Position For cylinder 1 - 2 Supplementary Article/Info 2 With piston ring carrier Without cooling channel Surface Coated Mechanically processed With recess for oil sprayer Production Number 81 L 51 Packaging length [cm] 9,5 Packaging width [cm] 9,50 Packaging height [cm] 12,80 Recess Diameter [mm] 39,6 Recess Depth 1 [mm] 17,2 Warranty 2 years Bolt length [mm] 68,0 Component Number 1. R2.5 NW CrK 2. M 2.0 IFU P 3. DSF 3.0 Cr Length [mm] 69,8 Compression Height [mm] 45,75 Valve pocket depth 1 [mm] 1,35 Top land height [mm] 9 Net Weight [g] 850 Piston clearance [mm] 0,05 Cylinder bore [mm] 81,26 Bolt diameter [mm] 26,0 Similar products of other manufacturers
Manufacturer Manufacturer number Price IPSA PI002401 MAHLE 030 58 01 (this product) Manufacturer Manufacturer number Price WILMINK GROUP WG1104405 -
Original part numbers
074107071AA AUDI 074107071AA CUPRA 074 107 071 A A VW -
Manufacturer
Mahle/ Knecht filters specializes in everything that has to do with the internal combustion engine and its immediate environment
More than 140 renowned motorcycle and vehicle manufacturers now equip their engines with MAHLE engine parts and filters as standard.
At Winparts we offer the following products from Mahle, among others: -
