DLS 2-channel amplifier CCi2

Universally applicable

DLS 2-channel amplifier CCi2 DLS 2-channel amplifier CCi2, Image 2 DLS 2-channel amplifier CCi2, Image 3 DLS 2-channel amplifier CCi2, Image 4
  • DLS 2-channel amplifier CCi2
  • DLS 2-channel amplifier CCi2, Thumbnail 2
  • DLS 2-channel amplifier CCi2, Thumbnail 3
  • DLS 2-channel amplifier CCi2, Thumbnail 4

Product number: 1688021

Manufacturer number: 610CCI2

EAN: 7331644079729

£ 167.90

Incl. VAT
View product specifications
In stock
Delivery 17-12-2025

Free Shipping

Secure payment
  • Free 30 days exchanges
  • Any part, any car
  • Fast shipping: 2 days
  • Expert support

Ecommerce Europe Trustmark

Customer service: +31 85 070 52 25

Ask your question at our product specialists.

Questions and answers.

  • Specifications

    Reference Series - CCi2
    "Probably one of the best SQ amplifiers in the world in terms of price/performance".

    Two-channel audiophile amplifier for high demands, tuned by Gordon Taylor. The prized DLS sound is ensured by linear regulators feeding the preamp and a high bias drive circuit.
    Combined with top quality output devices, this makes the DLS amplifiers simply sonically superior to the competition.
    Sparkling details with warm mids and an industry-leading S/N ratio of over 110 dBA - the amplifier is dead quiet!

    When used for system integration, the CCi2 includes a DLS High Level converter with auto start for upgrading OEM radios and a wide input level.
    Another useful feature of the High Level input is that a low-level output to additional amplifiers can be obtained via the RCA input connectors.

    Number of channels - 2
    Reinforcement class - AB
    Mono bridge mode 4 ohm -340 Watts
    Output power into 2 ohms -2 x 170 Watts
    Output power into 4 ohms - 2 x 110 Watts
    Damping factor >150
    THD at 5W, 20 Hz - 20 kHz. <0.25%
    S/N ratio, A-weighted >110 dB
    Frequency range 10 Hz - 50 kHz
    Input sensitivity 1 - 4 Volts
    Input impedance 6 kohm
    Input impedance, high level 45 ohms
    High pass filter 50 - 500Hz
    Low-pass filter 50 - 500Hz
    High level input with automatic start Yes
    Power consumption (idle) 0.5 A
    Power consumption (max) 43 A
    Integrated fan
    Dimensions (W x D x H) 129 x 260 x 51 mm (5.1? x 10.2? x 2?)
    Weight 1.87 kg

    Suitable for:
    2-Channel
    Output340 watts
    Number of channels2
    Warranty2 years
