BlackVue DR770X-1CH Full HD Cloud Dashcam 256GB

BlackVue DR770X-1CH Full HD Cloud Dashcam 256GB

The best full HD cloud dashcam. The camera is equipped with a Full HD Sony Starvis™ image sensor (60 fps). This ensures clear and smooth recordings in all lighting conditions.

1. Secure your vehicle at the front
2. GPS
3. WiFi
4. Cloud
5. Impact detection
6. Motion detection
7. Extended parking mode
8. And much more

Model name: DR770X-1CH
Colour/Size/Weight Black/Width: 118.5mm x Height 36mm/103g
Memory microSD card: (64 GB/128 GB/256 GB)

Recording modes

Normal recording, Activity recording (when collision
is detected in normal and parking mode),
Manual recording and Parking recording (when
motion is detected)
* When you use a wired power cord,
ACC+ activates parking mode. When you other
methods used, G sensor will enter the parking mode
activate.

Camera: STARVISTM CMOS Sensor (approx. 2.1M Pixel)
Viewing angle: diagonal 139°, horizontal 116°, vertical 61°
Resolution/Frame Rate: Full HD at 60 fps

* Frame rate may differ during Wi-Fi
streaming.

Image quality: Highest (Extreme), Highest, High, Normal
Video compression mode: MP4
Wi-Fi: built-in (802.11 bgn)
GPS: built-in (Dual-Band: GPS, GLONASS)
Bluetooth: built-in (V2.1 + EDR/4.2)
LTE: external
Microphone: built-in
Speaker(Voice guidance): built-in
Lights: Recording LED, GPS/BT LED, Wi-Fi LED, Front Security LED, Proximity Sensor LED

Test
Wi-Fi button:
* Press once to turn Wi-Fi on or off.
Proximity sensor:
Touching the proximity sensor starts audio recording
on/off or manual recording is activated,
depending on the firmware settings.

Sensor: 3-axis acceleration sensor
Spare battery: built-in super capacitor
Input power: DC 12 V - 24 V (DC Plug (Ø3.5 x Ø1.35)) to wires (black: GND / yellow: B+ / red: ACC)

Energy consumption

Normal mode (Wi-Fi on / GPS on): 275mA/hour
Normal mode (Wi-Fi off / GPS on): 240mA/hour
Parking mode (Wi-Fi on / GPS off): 220mA/hour
Parking mode (Wi-Fi off / GPS off): 185mA/hour
* Actual energy consumption may vary depending
of the usage and environmental conditions.

Operating temperature: -20°C - 85°C (-4°F - 185°F)
Storage temperature: -20°C - 90°C (-4°F - 194°F)
High temperature interruption: Approx. 85°C (185°F)
Certifications: FCC, CE, RoHS, Telec, WEEE, IC

Software: BlackVue Viewer * Windows 7 or newer and Mac Yosemite OS

Other: Custom format-free file management system

Suitable for:
Dashcam
