GAS MAD Level 1 Subwoofer 12" 4 Ohm

The MAD subwoofers are built to be loud and last for years. Those amazing vibrations are what drives us to create impressive subwoofers. We want to help you and your vehicle be as loud as possible. We have ensured this by using innovative and groundbreaking techniques that increase sustainability.

CAST POLYPROPYLENE CONUS
We wanted to make the MAD S1 series really loud and that requires a sturdy cone. The cone of the S1 series is made of injection molded polypropylene that can withstand the toughest resonances and membrane ruptures.

DVS™ VENTILATION SYSTEM
If you like LOUD, good cooling is essential. We equipped the subwoofer with a DVS™ (Dual Ventilation System) for less distortion and better heat dissipation. Good cooling means less heat and less heat gives you the opportunity to add more subwoofers for an even louder sound!

HOUSING OPTIMIZED
The MAD S1 series is both loud and impressive. We have created a subwoofer with multi-talented Thiele/Small parameters that ensure great performance in both sealed, vented and bandpass enclosures. Line the enclosure with polyfill to reduce the BOOM and bring out the BASS!

MAD DESIGN
To complete the subwoofer's high-quality construction, we created an industrial and rugged MAD-shaped steel basket that is resilient and strong. The 51mm voice coil is made of PCW (Pure Copper Wire) and the dust cover, like the cone, is made of IMPP for a unique 3D design that will make your friends jealous and keep the haters at bay! Walk big and cruise with pride!

Series: MAD
Component: Subwoofer
Size: 12 inches
Nominal Impedance: 4 Ohms
Power RMS: 300W
Power MAX: 600W
Freq. Response: 27-200 Hz
Cone: IMPP
Magnet: Ferrite
Voice Coil: 2 Inch (51mm) PCW
Dust cap: 3D IMPP
Basket: M Steel
Suspension: USG™ Rubber

Suitable for:
12 Inches

---

application	Subwoofer release
Power	600w
Subwoofer size	12 Inch
Warranty	2 years
